Basic Electronics (MCQs With Explanatory Answers)

Explanatory Answer:

Diamond has the highest bandgap energy, about 6eV. It is this high bandgap which separates the filled valance band from the conduction band and makes Diamond an insulator. Though Graphite is also a form of Carbon, like Diamond, its crystal symmetry is different and band gap energy is about 1eV, making it a conductor. Bandgap energy of Silicon is about 1.21eV, which can be acquired only with increase in temperature, making it a semiconductor.

Explanatory Answer

Below are the band gap energy relations with temperature for both Silicon and Germanium

E_gsi (T) = 1.21 – 3.60 x 10^-4

E_gge (T) = 0.785 – 2.23 x 10^-4

Substituting T = 300 in both the above equations, we get Bandgap energies as given below;

E_gsi (300) = 1.1 eV

E_gge (300) = 0.72 eV

Explanation:

Current Density in any conducting material is given as:

 J=( nµ_n + pµ_p ) eE= σE

Where, n = concentration of electrons, p  = concentration of holes, e = charge, E = applied electric field, and σ = conductivity.

Thus it can be seen that the electrical characteristics depends on concentration of electrons and holes. Thus, the above statement is true.

Explanatory Answer:

Two ways in which charge carriers are transferred in semiconductor are – conduction and diffusion

Conduction in semiconductor is accomplished by movement of free electrons and holes. While electrons are negative charge carrying particles, holes are positive charge carrying particles. Both their current is in same direction.

Diffusion is caused by movement of charge carriers from higher concentration area to lower concentration area. This is possible because of non-uniform concentration in semiconductors.

Explanatory Answer:

As per Einstein’s equation for diffusion,

Where, D_{n =} Electron Diffusion Constant, D_P = Hole Diffusion Constant, µ_p = Hole Mobility, µ_n  = Electron Mobility and V_T = Volt equivalent of temperature, = T/11600.

At room temperature, i.e. T = 300°K, VT = 0.0258 V approx

Substituting D_n = 99 and VT = 0.025 in the above equation, we get µ_n  = 3837.20 or 3800 approx.

Explanation: For an intrinsic semiconductor with equal concentration of holes and currents, the carrier lifetime for free electrons and holes is determined by the rate of recombination. While new electron-hole pairs are formed due to thermal agitation, existing electron-hole pair disappear due to recombination.

Explanation: Addition of metallic impurities in the semiconductor introduces new energy states in the forbidden gap of the semiconductor crystal, thus increasing the level of recombination.

Hall effect is the phenomenon of induction of electric field in a semiconductor specimen carrying current of magnitude I, when placed in a transverse magnetic field, B. If current is in positive X direction, Magnetic field is in positive Z direction, force will be exerted in negative Y direction. The polarity of voltage, V_H across the specimen determines whether it is N-type or P-type.

Also, carrier concentration is determined as:

n (p) = ρ/e, where ρ = charge density and e is magnitude of charge

Now, ρ = 1/R_H,, where R_H is Hall coefficient and is given as: R_H = V_Hw/BI

w = width of the specimen in direction of magnetic field.

Explanatory Answer:

For a P-N junction diode, the space charge region is the region devoid of mobile charge carriers near to the junction. The electro-static potential variation in this region forms a potential barrier which opposes further diffusion of opposite charge carriers across the junction.

Explanatory Answer: Addition of donor atoms into one side of an intrinsic semiconductor (like Germanium) and acceptor atoms into another side, causes formation of a junction. Under no external applied electric field, a potential barrier exists across the junction due to formation of depletion region (depletion of mobile charge carriers). However, when an external electric field is applied such that p-region is of positive polarity and n-region is of negative polarity, the potential barrier is reduced, causing flow of current. This is called Forward biasing.

When the opposite occurs, i.e. p-region is of negative polarity and n-region is of positive polarity, the potential barrier is increased, hindering the flow of current. Thus,  since the p-n junction device would allow flow of electricity in only one half of the electric signal, but not in the other half, this constitutes rectifying action.

Explanatory answer: For a Germanium diode, the breakdown voltage is about 0.2 V, whereas that of Silicon diode is 0.6 Volts. The reason being that, reverse saturation current in a Ge diode is about 1000 times more than that in Si diode. Also, current flowing through the diode is as given below;

I = I_o ( e ^V/ηV_T  – 1 )

For Ge, the symbol  η = 1, whereas that for Si is 2 for small currents and 1 for large currents. Hence, for first several tenths of volts, the current varies as e ^V/2V_T.

Explanatory answer: Intrinsic concentration for any semiconductor is as given below;

ni² = A_o T³ e ^-E_GO  / kT)

Conductivity of intrinsic Germanium varies with concentration as given below;

σ = n_i (µ_n+ µ_p ) e

Substituting the constant values for intrinsic Germanium and merging both the above equations, we get that conductivity increases by approximately 6% per degree rise in temperature.
